Datasheet Wago 250-117/000-012 — Даташит
Клеммная колодка для печатной платы; Кнопка; 1,5 мм²; Шаг контактов 3,5 мм; 17-полюсный; Зажим Push-in CAGE CLAMP
Цены
Printed circuit board terminal | |||
| 250-117/000-006 Wago | по запросу | ||
Параметры
| Actuation type | Push-button |
| Clamping spring material | Chrome nickel spring steel (CrNi) |
| Цвет | orange |
| Conductor entry angle to the PCB | 45 ° |
| Connection technology | Push-in CAGE CLAMP® |
| Contact material | Electrolytic copper (Ecu) |
| Contact plating | tin-plated |
| Country of origin | CH |
| Габариты: глубина | 12 mm / 0.472 inch |
| Drilled hole diameter (tolerance) | 1(+ 0.1) мм |
| Fine-stranded conductor | 0.2 … 1.5 mm² / 24 … 16 AWG |
| Fine-stranded conductor with ferrule with plastic collar | 0.25 … 1 mm² |
| Fine-stranded conductor with ferrule without plastic collar | 0.25 … 1 mm² |
| Flammability class per UL94 | V0 |
| GTIN | 4017332329156 |
| Height | 16.7 mm / 0.657 inch |
| Height from the surface | 13.1 mm / 0.516 inch |
| Insulating material | Polyamide 66 (PA 66) |
| Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
| Limit temperature range | -60 … +105 °C |
| Material group | I |
| Number of Poles | 17 |
| Number of connection types | 1 |
| Number of levels | 1 |
| Number of solder pins per potential | 1 |
| PCB contact | THT |
| Pin spacing | 3.5 mm (0.138 inch) |
| Product Group | 4 (Printed Circuit) |
| Rated current | 8 A |
| Rated impulse voltage (II / 2) | 2.5 kV |
| Rated impulse voltage (III / 2) | 2.5 kV |
| Rated impulse voltage (III / 3) | 2.5 kV |
| Rated voltage (II / 2) | 320 В |
| Rated voltage (III / 2) | 160 В |
| Rated voltage (III / 3) | 160 В |
| Solder pin arrangement | over the entire terminal strip, in line |
| Solder pin dimensions | 0.4 x 0.75 mm |
| Solder pin length | 3.6 мм |
| Solid conductor | 0.2 … 1.5 mm² / 24 … 16 AWG |
| Strip length | 8.5 … 9.5 mm / 0.33 … 0.37 Inch |
| Total number of connection points | 17 |
| Total number of potentials | 17 |
| Вес | 7.701 г |
| Ширина | 61 mm / 2.402 inch |
