Datasheet Wago 236-767 — Даташит
Стекируемый клеммный блок для печатных плат; 2,5 мм²; Шаг контактов 10/10,16 мм; 1-полюсный; CAGE CLAMP; возможность объединения
Цены
Купить 236-767 на РадиоЛоцман.Цены — от 36 до 45 691 ₽ 5 предложений от 5 поставщиков STACKABLE PCB TERMINAL BLOCK; 2. | |||
| 236-767 Wago | 36 ₽ | ||
| 236767 | 2 567 ₽ | ||
| 236767GY | 45 691 ₽ | ||
| 236-767 | по запросу | ||
Параметры
| Actuation type | Operating tool |
| Clamping spring material | Chrome nickel spring steel (CrNi) |
| Цвет | light green |
| Conductor entry angle to the PCB | 45 ° |
| Connection technology | CAGE CLAMP® |
| Contact material | Electrolytic copper (Ecu) |
| Contact plating | tin-plated |
| Country of origin | CH |
| Габариты: глубина | 14 mm / 0.551 inch |
| Drilled hole diameter (tolerance) | 1.1(+ 0.1) мм |
| Fine-stranded conductor | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Fine-stranded conductor with ferrule with plastic collar | 0.25 … 1.5 mm² |
| Fine-stranded conductor with ferrule without plastic collar | 0.25 … 1.5 mm² |
| Fire load | 0.023 MJ |
| Flammability class per UL94 | V0 |
| GTIN | 4044918775007 |
| Height | 17 mm / 0.669 inch |
| Height from the surface | 13 mm / 0.512 inch |
| Insulating material | Polyamide 66 (PA 66) |
| Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
| Limit temperature range | -60 … +105 °C |
| Material group | I |
| Number of Poles | 1 |
| Number of connection types | 1 |
| Number of levels | 1 |
| Number of solder pins per potential | 2 |
| PCB contact | THT |
| Pin spacing | 10/10.16 mm / 0.394/0.4 inch |
| Product Group | 4 (Printed Circuit) |
| Rated current | 24 A |
| Rated impulse voltage (II / 2) | 8 kV |
| Rated impulse voltage (III / 2) | 8 kV |
| Rated impulse voltage (III / 3) | 8 kV |
| Rated voltage (II / 2) | 1000 В |
| Rated voltage (III / 2) | 1000 В |
| Rated voltage (III / 3) | 630 В |
| Solder pin arrangement | within the terminal block, in line |
| Solder pin dimensions | 0.7 x 0.7 mm |
| Solder pin length | 4 мм |
| Solid conductor | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Strip length | 5 … 6 mm / 0.2 … 0.24 Inch |
| Total number of connection points | 1 |
| Total number of potentials | 1 |
| Вес | 1.267 г |
| Ширина | 12.2 mm / 0.48 inch |
Модельный ряд
Серия: 236 (100 из 244)
- 236-602/332-009/999-950 236-603 236-603/000-004 236-603/000-009/999-950 236-603/000-017 236-603/332-009/999-950 236-604 236-604/000-009/999-950 236-604/332-009/999-950 236-605 236-606 236-606/000-009/999-950 236-606/332-009/999-950 236-607 236-608 236-608/000-009/999-950 236-608/332-009/999-950 236-609 236-612 236-612/000-009/999-950 236-612/332-009/999-950 236-616 236-616/000-009/999-950 236-616/332-009/999-950 236-623 236-624 236-624/000-009/999-950 236-624/332-009/999-950 236-700 236-710 236-711 236-712 236-713 236-714 236-715 236-716 236-717 236-722 236-723 236-724 236-725 236-726 236-727 236-732 236-733 236-734 236-735 236-736 236-737 236-740 236-741 236-742 236-742/332-000 236-743 236-743/332-000 236-743/332-000/999-950 236-743/999-950 236-744 236-744/332-000 236-745 236-746 236-746/332-000 236-747 236-747/332-000 236-752 236-752/332-000 236-753 236-753/332-000/999-950 236-753/999-950 236-754 236-755 236-756 236-757 236-757/332-000 236-762 236-762/332-000 236-763 236-763/332-000/999-950 236-763/999-950 236-764 236-764/332-000 236-765 236-766 236-766/332-000 236-767 236-767/332-000 236-800 236-850 236-851 236-852 236-853 236-854 236-855 236-856 236-881 236-882 236-884 236-885 236-891 236-894
Классификация производителя
- PCB Interconnect
